Gravity Simulator

What is GravitaSim?

GravitaSim is a small application that graphically simulates the Newton’s law of universal gravitation.

It is a free and cross-platform 3D simulator that contains realistic and fictional scenarios in which objects with masses and velocity vectors are positioned and interact with one another according to the law of gravitation.

Real-world scenarios include our own solar system. In this particular scenario, the mass of objects, coordinates, and velocity vectors are obtained from NASA's Jet Propulsion Laboratory.

All scenarios can be changed or added by modifying existing files or creating new ones.

This simulator is written in C++ (more precisely, C with classes), is freeware, and does not contain any advertising, spyware, or other form of user tracking.

It is available for Windows, Linux, and macOS and will be a work in progress.

Minimum recommended hardware requirements

GravitaSim is compiled on Linux, Windows, and macOS platforms. It should therefore run on any of these operating systems.

It was successfully tested on the following OS :

Installation

Windows and Linux users :

GravitaSim can be used without the need to install it. It can run from a cloud folder, an external device, or a local folder.

Download the zipped file. Unzip the downloaded file to a folder of your choice and run the application. In some Unix-like systems, you might need to launch the application from a terminal window.

Simply delete the folder to uninstall.

Mac users :

Download the dmg file and open it.

To install the application just drag “GravitaSim.app” into the Applications folder. GravitaSim is now installed and should be available in Launchpad. After being installed, you can eject and delete the downloaded dmg file.

To uninstall the application, drag “GravitaSim.app” from the Applications folder into the bin and delete the GravitaSim folder containing the scenarios and settings located in the Downloads folder.

Gravitational scenarios pictures

GravitaSim can be used for amusement purposes where we have more or less complex patterns like these black holes attracted to one another and moving symmetrically or as in the following figure, the stars with the green trajectories.

Alternatively, it can be used in a more descriptive way, enabling the analysis of gravitational data pertaining to the objects placed in the scenario. Similar to how these four planets, which are the same size and mass as the Earth, will affect Saturn's rings as they pass by.

Our solar system.

Jupiter trojans formation and Lagrange points.

Did you learn in school that only planets move? That the stars remain stationary in space? Was wrong. Our Sun is traveling at a speed of about 48 kilometers per hour (30 miles per hour) due to the gravitational influence of the planets in the solar system.

Detecting this wobble movement that some stars have is one of the techniques used by astronomers to detect exoplanets (planets from other solar systems in our galaxy).

Mouse Navigation

Mouse commands are summarized in the following tables, and use the following abbreviations:

Keyboard shortcuts

Almost all user interaction is made with the mouse, keyboard shortcuts are just an alternative but they can effectively be faster and more convenient.

Universal Law of Gravitation

In 1687, an English mathematician and physicist, Isaac Newton put forward this law to explain the observed motions of planets and their moons. Newton's law of universal gravitation states that any particle of matter in the universe attracts another one with a force varying directly as the product of the masses and inversely as the square of the distance between them.

F is the gravitational force, G is the gravitational constant, m1 and m2 are point-like masses, and r is the distance between the masses.

Let's take the classical example of Earth and Moon. We'll consider 384000km (238606Mi) as the average distance between them:

What if the moon was in freefall toward Earth?

In the scenario "earthmoon.scn" the moon has stopped orbiting the earth and is falling free towards our planet.

• How long would it take for the Moon to reach Earth?
• How fast is the Moon when it hits Earth?
• What is the speed of the Earth at the time of the collision?
• How far would the Moon and Earth travel?

At the time of impact, the approach speed between the Earth and the Moon would be 9870 m/s (22081Mph)

Earth and Moon would be moving respectively at 119.93m/s (268.3Mph) and 9750m/s (21812Mph).

The time required for impact would be approximately 4 days 19 hours and 25 minutes. During this period of time, Earth would travel 4567 km (2837.8 mi). And the Moon the remaining 371324 km (230730 mi)

Downloads

Windows 64Bits

117.16.12.2025

Linux 64Bits

117.16.12.2025

macOS

117.16.12.2025

If upgrading GravitaSim, the scenario folder from the previous version should be deleted.
The new version might not be compatible with old scenarios.

Comments or suggestions
